Eaton Tripp Lite Series Power Extension Cord/Splitter, 2 x C19 to C20 Y Splitter - Heavy-Duty, 20A, 250V, 12 AWG, 6 ft. (1.83 m), Black - 20A, 12AWG (2x IEC-320-C19 to IEC-320-C20) 6-ft."
- Connect two devices to one power outlet
- Plug type - C20 to 2 x C19
- 12AWG (3.31mm²), SJTW, 20A, 100-250V
General Information
| Manufacturer |
Eaton Corporation |
| Manufacturer Part Number |
P036-006-2C19 |
| Manufacturer Website Address |
http://www.eaton.com |
| Brand Name |
Tripp Lite series |
| Product Model |
P036-006-2C19 |
| Product Name |
P036-006-2C19 Splitter Cable |
| Marketing Information |
Tripp Lites P036-006-2C19, 6ft Universal AC Power Cord Splitter, allows you to connect two devices with C20 connections, such as blade server chassis, to one power outlet. Cuts down on cabling, as well as frees up space on UPS's, Surge Protectors, PDU's etc. Main trunk cable measures 47" from C20 plug to the splitter housing, 3" housing, and 22" each on the two C19 legs. Tripp Lite Lifetime Warranty. More from the Manufacturer
|
| Product Type |
Splitter Cord |
Technical Information
| First End Connector Type |
IEC 60320 C19 |
| First End Connector Detail |
2 x IEC 60320 C19 |
| Second End Connector Type |
IEC 60320 C20 |
| Second End Connector Detail |
1 x IEC 60320 C20 |
| Device Supported |
Computer |
| Device Supported |
Server |
Power Description
| Voltage Rating |
110 V AC |
| Voltage Rating |
220 V AC |
| Current Rating |
20 A |
Physical Characteristics
| Cord Length |
6 ft mm |
| Color Family |
Black |
| Product Color |
Black |
Miscellaneous
| Compatibility |
- Computer
- Blade Server Chassis
|
| Country of Origin |
Vietnam |
| Environmentally Friendly |
Yes |
| Environmental Compliance |
Restriction of Hazardous Substances (RoHS) |
Warranty
| Limited Warranty |
Lifetime |
